UTUBE NUMBER: 1930
MANUFACTURER: DAHLSTROM
MODEL NUMBER: 28-18-17
SERIAL NUMBER: S-332
SPECIFICATIONS:
Roll space: 28″
Roll Arrangement:
(1) Pass Line Roll 2″ Dia. w/Edge Guides
(2) Pinch Rolls Vertical, 3-1/2″ Dia. x 24″ Face
8 Over 7 Work Rolls, 2-11/16″ Dia. x 24″ Face
Capacity: .048″
EQUIPPED WITH:
Air Quick Lift to All Work Rolls
Push Buttons
Speed Control
Manual Cross Connected Roll Depth Adjustment
Central Grease Lubrication
Footage Counter
Drive: 7.5/15 HP, 240 V DC w/Drive and Controls, Speed: 40 – 120 80 – 240 FPM
CONDITION: Good, Cleaned, & Checked Over
OVERALL DIMENSIONS: 10′ x 6′ x 7′
APPROXIMATE WEIGHT: 5,000 Lbs.
LOCATION: Universal Warehouse, Perrysburg, Ohio
