3″ (76.2 mm) x .120″ (3.04 mm) HAVEN #912 Double End Facer Parts Machine

Stock #: 3784

SKU: 3784 Categories: , Tag:

UTUBE NUMBER: 3784
MANUFACTURER: HAVEN
MODEL NUMBER: 912
SERIAL NUMBER: 2875A

SPECIFICATIONS:
Maximum Tube Diameter: 3″ (76.2 mm)
Minimum Tube Diameter: 1/2″ (12.7 mm)
Maximum Wall Thickness: .120″ (3.04 mm)
Minimum Wall Thickness: .028″ (.711 mm)
Length: 6″ – 60″

Tube Finish:
• 30 Degree I.D. Chamfer, 30 Degree O.D. Chamfer
• End Face Flat & Square to Center Line of Tube
Feed: Adjustable, Electric
Pneumatic: 80 PSI – 4 Bar
Spindle Drives: (2) 7.5 HP Motors

NOTE: Parts machine, missing hydraulic unit and miscellaneous parts

OVERALL DIMENSIONS: 12′ x 7′ x 6.5′
APPROXIMATE WEIGHT: 5,000 Lbs.
LOCATION: Universal Warehouse, Perrysburg, Ohio

CARE IS TAKEN TO GIVE A RELIABLE DESCRIPTION OF THIS HAVEN END FACER PARTS MACHINE BUT THESE ARE NOT GUARANTEED. PROSPECTIVE PURCHASERS ARE ADVISED TO CHECK VITAL DETAILS. WE RESERVE THE RIGHT TO CORRECT STENOGRAPHIC ERRORS. ALL MACHINERY IS SUBJECT TO PRIOR SALE. CLICK HERE TO READ THE TERMS AND CONDITIONS OF SALE THAT APPLY TO THIS HAVEN END FACER PARTS MACHINE. VISIT UNIVERSALCONTROLSGROUP.COM FOR INFORMATION ON NEW CONTROL PANELS, DRIVE SYSTEMS AND PLANT AUTOMATION.
