UTUBE NUMBER: 3573
MANUFACTURER: HAVEN
MODEL NUMBER: 872
SERIAL NUMBER: 2758
YEAR:
SPECIFICATIONS:
Maximum Tube Diameter: 3" (76.2 mm)
Maximum Squares & Rectangles: 3" (76.2 mm) Diagonal
Minimum Tube Diameter: 1/2" (12.7 mm)
Maximum Wall Thickness: .120" (3.04 mm)
Line Direction: Left to Right
Cycle Speeds: Up to 5,000 Cycles/Hr
Maximum Cut Length: 6′
EQUIPPED WITH:
20′ Bundle Loader
Push Button Console
VICKERS Hydraulic Pump
Target Assembly
Central Grease System
30 HP Motor: 230 / 460 / 60 Hz / 3 Phase
BURRMASTER Double End Brush Machine
Air Heat Exchanger for Cooling Hydraulic Oil
Exit Conveyor
CONDITION: Good As Taken From Service (was running production in 2018)
OVERALL DIMENSIONS: 1 Truckload
APPROXIMATE WEIGHT: 17,000 Lbs.
LOCATION: Universal Warehouse, Perrysburg, Ohio
