UTUBE NUMBER: 3629
MANUFACTURER: MCKAY
MODEL NUMBER:
SERIAL NUMBER: 7605
YEAR:
SPECIFICATIONS:
Maximum Coil Weight: 15,000 Lbs. (Approximate)
Maximum Coil Width: 42″
Coil I.D. Range: 16″ – 22″
Maximum Coil O.D.: 96″
EQUIPPED WITH:
4 Arm Hydraulic Expansion
Hydraulic Unit
(3) Coil Keepers
Air Brake
Motor, 5 HP
OVERALL DIMENSIONS: 7′ x 9′ x 7′
APPROXIMATE WEIGHT: 1,500 Lbs.
LOCATION: Universal Warehouse, Perrysburg, Ohio
