UTUBE NUMBER: 3189
MANUFACTURER: TISHKEN
MODEL NUMBER: 10 HM 1-1/2
SERIAL NUMBER: 689-441
YEAR:
SPECIFICATIONS:
Line Direction: Left to Right
Number of Stands: 10
Spindle Diameter: 1-1/2"
Roll Space: 6"
Horizontal Centers: 8"
Vertical Adjustment: 4-1/2" – 5-1/2"
Base Top to Center Lower Spindle: 4-1/2"
Spindle Key Size: 1/4"
Gearing: Equal
EQUIPPED WITH:
Straightener Stand
Motor
Push Button Console
OVERALL DIMENSIONS: 9′ x 5′ x 5′
APPROXIMATE WEIGHT: 5,800 Lbs.
LOCATION: Universal Warehouse, Perrysburg, Ohio
